AUDIO VIDEO CABLES
1 mm TOSLINK SPDIF Digital Optical Audio Cable
This is a TOSLINK S/PDIF digital optical audio cable — EMI-immune POF with molded optical connectors for soundbars, DACs, TVs and receivers, eliminating ground loops.
Specifications
- Type
- Fiber Optic Cable
- Application
- Sensing,Lighting ,Communication, Transmission signal
- Fiber type
- PMMA fiber optic cable
- Certification
- ISO9001, RoHS,CE
- Core diameter
- 1.0mm
- Outer diameter
- 2.2mm
- Operating temperature
- -55~80Degree
- IP rating
- IP68
- Outer material
- PE
- Core Material
- pmma
- Length
- 1000m/roll
1 mm TOSLINK SPDIF Digital Optical Audio Cable
This is a JINSHANG TECH TOSLINK (SPDIF) digital optical audio cable using POF to carry stereo and multi-channel audio electrically isolated from source to DAC or soundbar.
Manufactured for production use rather than as a one-off sample, the unit is built to a stable fiber specification so orders can be repeated with consistent dimensions and performance.
Key Characteristics
- Operating temperature range: -55~80Degree
- IP68 ingress protection for damp or wash-down environments
- Standard length: 1000m/roll
- Certified to ISO9001, RoHS,CE
- Outer jacket: 2.2mm
- Core/fiber material: 1.0mm
- Carries S/PDIF stereo, Dolby/DTS multi-channel and PCM audio as light
- Complete electrical isolation eliminates ground loops and mains hum
Typical Applications
The unit is commonly used for TV, soundbar, AV receiver, game console and DAC connections, digital-to-analog converters and multimedia audio, and noise-free audio links in home theater and studio setups. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: What is a TOSLINK optical cable for? A: It carries S/PDIF digital audio (PCM and compressed surround) between devices as light, avoiding the hum and ground loops common with copper audio leads.
Q: Is TOSLINK the same as mini-TOSLINK? A: Mini-TOSLINK uses a smaller 3.5 mm-style connector; check the port on your device — adapters or a dedicated mini lead are used where required.
Q: Will it remove background hum? A: Because the link is optically isolated there is no electrical ground between devices, which typically eliminates ground-loop hum.
Q: What audio formats does it pass? A: Standard S/PDIF optical carries stereo PCM and compressed Dolby/DTS bitstreams; it does not carry HDMI-only high-bitrate formats.
