OPTICAL FIBER CABLES
Toshiba Industrial Fiber Optic Cable Harness Assembly
This is a factory-terminated industrial fiber-optic harness — EMI-immune optical cable assembly for servo drives, CNC and factory automation networks.
Specifications
- Type
- Backshell
- Application
- Medical sensing system, server system, Communication switching system, Power Systems, Digital multimedia system, Industrial robot intelligent system, Power automation control bus system
- Color
- Golden
- Certificate
- ISO9001 RoHS
- Insertion Loss
- 0.2
- Return loss
- 0.2
- Plug-in times
- 10000 Supply Ability Supply Ability 10000 Piece/Pieces per Week
Toshiba Industrial Fiber Optic Cable Harness Assembly
This is a Toshiba industrial fiber-optic cable assembly (harness) terminated with factory connectors for direct installation in servo, CNC and control systems.
Manufactured for production use rather than as a one-off sample, the unit is built to a stable fiber specification so orders can be repeated with consistent dimensions and performance.
Key Characteristics
- Insertion loss: 0.2
- Return loss: 0.2
- Factory-terminated connectors for consistent, low-loss performance
- EMI-immune optical link between servo drives, amplifiers and controllers
- Flexible, drag-chain-compatible jacketing where specified
- Available in multiple standard lengths with custom lengths on request
- Drop-in replacement for industrial OEM optical cables
- Galvanically isolated, spark-free and electrically quiet
Typical Applications
The unit is commonly used for machine and equipment harnesses requiring OEM-form fit. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: What is a fiber-optic harness? A: It is a factory-terminated optical cable with connectors installed on both ends, ready to plug into servo drives, controllers or modules without field termination.
Q: How do I choose the length? A: Standard lengths are listed in the specifications; custom lengths can be produced by confirming the routing distance and connectors.
Q: Why use fiber in a servo system? A: Optical links are immune to drive-generated EMI and provide galvanic isolation, improving reliability in noisy motion-control cabinets.
Q: Is it a direct replacement for the OEM cable? A: The harness is built to match the listed fiber type and connector interfaces, so confirm the model/part number against the original equipment before ordering.
