U-DQ(ZN)11Y 8G50/125 OM3 3.5mm for MPO connector termination
U-DQ(ZN)11Y 8G50/125 OM3 3.5mm for MPO connector termination
U-DQ(ZN)11Y 8G50/125 OM3 3.5mm for MPO connector termination
Application | |
This cable is suitable for industrial application,designfor MPO connector termination,Cable for flexible applications indoor | |
| |
Standard | |
IEC 60793-2-10 Cat.A1a.1 | Multi-mode fiber |
IEC 60794-2 | In-door cable |
IEC 60794-1-2 | Cable type test |
Structure | |
Fiber | |
Core diameter | 50 ± 1 um |
Cladding diameter | 125 ± 2 um |
Coating diameter | 245 ± 10 um |
Color | Blue, Orange, Green, Brown, Grey, White, Red, Black |
Reinforce element | |
Aramid | |
Jacket | |
Material | TPU |
Diameter | 3.5 ± 0.3 mm |
Color | Black |
Printing | ALPTICS U-DQ(ZN)11Y 8G50/125 OM3 3.5mm xxxxM WW/YY |
| |
Optics Performance | |
Attenuation | < 3.2 dB/km @850 nm |
| < 1.0 dB/km @1300 nm |
Bandwidth | > 200 MHz·km @850 nm |
| > 500 MHz·km @1300 nm |
NA | 0.275 ± 0.015 |
| |
Mechanical Parameter | |
Tensile strength | > 80 N Long term |
| > 150 N Short term |
Bending radius | > 50 mm Long term |
| > 30 mm Short term |
Crush | >200 N/dm |
Drag Chain | Bending radius 50 mm |
| Travel speed 10 m/s |
| Acceleration 10 m/s² |
| Cycles 10 mil. |
| |
Climate Properties | |
Storage and transportation | -25 ℃ to + 70 ℃ |
During installation | 0 ℃ to + 50 ℃ |
Operation | -20 ℃ to + 70 ℃ |
| |
Flame Characteristic | |
Fire resist | |
