DC-265-7 Asahi Kasei Data Link POF Data Cable for Point-to-Point Optical Links
DC-265-7 DC-265-10 DC-500 jacketed PMMA plastic optical fiber data cable for EMI-immune point-to-point links. Large-core, easy-to-terminate POF for industrial and consumer networks.
Specifications
- Type
- Fiber Optic Cable
- Application
- Sensor,Lighting ,Communication, Transmission signal
- Fiber type
- PMMA fiber optic cable
- Certification
- ISO9001, RoHS, CE
- Core diameter
- 1.0mm
- Outer diameter
- 2.2
- Attenuation(dB/KM)
- ≤0.2
- Operating temperature
- -55~80Degree
- IP rating
- IP68
- Core Material
- pmma
DC-265-7 Asahi Kasei Data Link POF Data Cable for Point-to-Point Optical Links
DC-265-7 DC-265-10 DC-500 is a Asahi Kasei graded PMMA/POF communications cable engineered for high-bandwidth, easy-to-terminate optical links in industrial and consumer networks.
Manufactured for production use rather than as a one-off sample, the DC-265-7 DC-265-10 DC-500 is built to a stable fiber specification so orders can be repeated with consistent dimensions and performance.
Key Characteristics
- Certified to ISO9001, RoHS, CE
- Outer jacket: 2.2
- Core/fiber material: 1.0mm
- Fiber diameter: 1.0mm
- Attenuation rated at ≤0.2 over the operating wavelength
- Operating temperature range: -55~80Degree
- Simpler, lower-cost tooling than glass fiber — no fusion splicer required
- Large polymer core tolerates modest alignment, so termination is fast without high-precision cleaving
Typical Applications
The DC-265-7 DC-265-10 DC-500 is commonly used for industrial point-to-point links between PLCs, drives, sensors and controllers. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: What distance and bandwidth does POF data cable support? A: Plastic optical fiber is aimed at short-range links (typically within a room, cabinet or machine). Exact bandwidth/length follows the grade (e.g. SH/GH/LH/MH series) and the transceiver wavelength; consult the grade specification for your bit rate.
Q: Why choose POF instead of copper for data? A: POF provides complete electrical isolation and is immune to EMI, so links remain stable near variable-frequency drives and motors without grounding or shielding concerns.
Q: Is POF data cable hard to terminate? A: No. Its large core tolerates alignment, and simple cutting/crimping tools are used — no laser safety training or fusion splicer is required.
Q: Which POF grade do I need? A: Lower-loss grades support longer/higher-speed links; standard grades suit short equipment connections. Match the grade to the attenuation and distance given in the specifications.
For the matching Versatile Link and HFBR assemblies, visit the FEV Electronics fiber catalog at www.fevelectronics.com.
