OPTICAL FIBER CABLES
GH4001-TR Mitsubishi ESKA POF Data Cable for Point-to-Point Optical Links
GH4001-TR GHAN4001-YL jacketed PMMA plastic optical fiber data cable for EMI-immune point-to-point links. Large-core, easy-to-terminate POF for industrial and consumer networks.
Specifications
- Type
- Fiber Optic Cable
- Application
- Data Point-to Point & Network
- Fiber type
- Eska Mitsubishi fiber optic cable
- Certification
- ISO9001, RoHS, CE
- Core diameter
- 1.0mm
- Outer diameter
- 2.2*4.4mm
- Operating temperature
- -55~80Degree
- IP rating
- IP68
- Core Material
- pmma
- efractive Index Profile
- Step Index
GH4001-TR Mitsubishi ESKA POF Data Cable for Point-to-Point Optical Links
GH4001-TR GHAN4001-YL identifies a Mitsubishi plastic optical data cable that combines large-core alignment tolerance with electromagnetic immunity for short-range networks.
JINSHANG TECH supplies the GH4001-TR GHAN4001-YL as a production item; fiber diameter, jacketing, connectorization and length can be confirmed against the specification before ordering.
Key Characteristics
- Outer jacket: 2.2*4.4mm
- Core/fiber material: 1.0mm
- Fiber diameter: 1.0mm
- Operating temperature range: -55~80Degree
- IP68 ingress protection for damp or wash-down environments
- Certified to ISO9001, RoHS, CE
- Light weight with good flexibility and vibration resistance for moving machinery
- No electrical continuity between nodes, providing galvanic isolation and spark-free links
Typical Applications
The GH4001-TR GHAN4001-YL is commonly used for industrial point-to-point links between PLCs, drives, sensors and controllers, and on-board and in-rack optical networking with simple connectorization. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: Which POF grade do I need? A: Lower-loss grades support longer/higher-speed links; standard grades suit short equipment connections. Match the grade to the attenuation and distance given in the specifications.
Q: What distance and bandwidth does POF data cable support? A: Plastic optical fiber is aimed at short-range links (typically within a room, cabinet or machine). Exact bandwidth/length follows the grade (e.g. SH/GH/LH/MH series) and the transceiver wavelength; consult the grade specification for your bit rate.
Q: Is POF data cable hard to terminate? A: No. Its large core tolerates alignment, and simple cutting/crimping tools are used — no laser safety training or fusion splicer is required.
Q: Can it be used in moving equipment? A: Yes. The polymer core and flexible jacket resist vibration and repeated flexing better than glass, making it suitable for machinery and light-motion applications.
