OPTICAL FIBER CABLES
Mitsubishi ESKA Industrial Fiber Optic Cable Harness Assembly
This is a factory-terminated industrial fiber-optic harness — EMI-immune optical cable assembly for servo drives, CNC and factory automation networks.
Specifications
- Type
- Backshell
- Application
- Automotive
- Color
- Black
- Product Brand
- Mitsubishi
- Insertion Loss
- 0.2
- Transmission loss
- 0.2
- Mating times
- 10000
- Certification
- ISO9001 ,ROHS ,CE
- Name of commodity
- Mitsubishi Servo Fiber Connector
- IP rating
- IP68
- Operating temperature
- -55~+85C
- Package
- Carton
- Weight
- 0.02kg
Mitsubishi ESKA Industrial Fiber Optic Cable Harness Assembly
This is a Mitsubishi industrial fiber-optic cable assembly (harness) terminated with factory connectors for direct installation in servo, CNC and control systems.
JINSHANG TECH supplies the unit as a production item; fiber diameter, jacketing, connectorization and length can be confirmed against the specification before ordering.
Key Characteristics
- Insertion loss: 0.2
- Operating temperature range: -55~+85C
- IP68 ingress protection for damp or wash-down environments
- Certified to ISO9001 ,ROHS ,CE
- Housing/jacket color: Black
- Flexible, drag-chain-compatible jacketing where specified
- EMI-immune optical link between servo drives, amplifiers and controllers
- Factory-terminated connectors for consistent, low-loss performance
Typical Applications
The unit is commonly used for servo drive and amplifier networks in motion control. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: What is a fiber-optic harness? A: It is a factory-terminated optical cable with connectors installed on both ends, ready to plug into servo drives, controllers or modules without field termination.
Q: How do I choose the length? A: Standard lengths are listed in the specifications; custom lengths can be produced by confirming the routing distance and connectors.
Q: Why use fiber in a servo system? A: Optical links are immune to drive-generated EMI and provide galvanic isolation, improving reliability in noisy motion-control cabinets.
Q: Is it a direct replacement for the OEM cable? A: The harness is built to match the listed fiber type and connector interfaces, so confirm the model/part number against the original equipment before ordering.
