POF CABLE
TB-1000 Asahi Kasei 1 mm PMMA End-Glow Fiber Optic Cable for Decorative Lighting
TB-1000 1 mm end-glow PMMA plastic optical fiber for star ceilings, luminous furniture and decorative lighting. Flexible, waterproof, cool-running POF supplied in continuous spool lengths.
Specifications
- Working Temperature(°C)
- -20~70
- IP Rating
- IP68
- Application
- Illumination&Signal Transmission,,Decoration, ceilling,lighting
- Fiber Type
- PMMA end glow fiber optic cable
- Grade Name
- DB-1000
- Fiber Dia. (mm)
- 1.0
- NA
- 0.5
- Attenuation (dB/m)
- 0.16
- Minimum Bending Radius(mm)
- 20
- Winding Length (m)
- 1,500/5,250
- Certification
- Reach, ISO9001
TB-1000 Asahi Kasei 1 mm PMMA End-Glow Fiber Optic Cable for Decorative Lighting
TB-1000 denotes a Asahi Kasei 1 mm PMMA end-glow fiber — a flexible, electrically passive light guide built for decorative lighting.
JINSHANG TECH supplies the TB-1000 as a production item; fiber diameter, jacketing, connectorization and length can be confirmed against the specification before ordering.
Key Characteristics
- Certified to Reach, ISO9001
- Attenuation rated at 0.16 over the operating wavelength
- Minimum bend radius: 20
- Operating temperature range: -20~70
- IP68 ingress protection for damp or wash-down environments
- Standard length: 1,500/5,250
- Works with standard LED/halogen fiber illuminators and remote light sources
- Cuts and terminates with simple tools; no polishing or fusion equipment required
Typical Applications
The TB-1000 is commonly used for decorative outlines for bars, restaurants, weddings and public buildings, and signal and indicator transmission where a passive light pipe is preferred. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: Is the fiber safe near water or in a ceiling? A: Yes. The fiber itself carries no electricity and stays cool at the emitting end, so it is suitable for wet areas and occupied spaces when paired with a remotely located light source.
