PCF CABLE
V-PIN 200/230 HCS Fiber Jumper Harness
V-PIN 200/230 um hard-clad silica (HCS) fiber jumper with factory connectors for high-bandwidth, EMI-immune servo and CNC optical links.
Specifications
- Type
- CONNECTOR FIBER OPTIC, Avago
- Application
- Industrial automation control bus system
- Certifaction
- ISO9001 ,ROHS
- Working temperature
- -55C ~70C
- Transmission wavelength
- 180~200dB/km
- Shipment
- DHL,FEDEX,UPS,EMS,DPEX,ARAMEX,POST...
- Connector
- AVAGO Connector
- Refractive Index
- Step Index
V-PIN 200/230 HCS Fiber Jumper Harness
V-PIN is a JINSHANG TECH 200/230 um hard-clad fiber jumper (e.g. CS-DL72/F07) for industrial optical control.
JINSHANG TECH supplies the V-PIN as a production item; fiber diameter, jacketing, connectorization and length can be confirmed against the specification before ordering.
Key Characteristics
- Operating temperature range: -55C ~70C
- Standard length: 180~200dB/km
- Certified to ISO9001 ,ROHS
- Operating wavelength: 180~200dB/km
- Refractive index figures: Step Index
- Robust jacketing for industrial routing
- Available in standard and custom lengths
- EMI-immune and galvanically isolated for servo networks
Typical Applications
The V-PIN is commonly used for Mitsubishi/Sumitomo servo and CNC optical networks, industrial automation links needing higher bandwidth than POF, and HCS jumpers between drives, amplifiers and controllers. The result is a reliable, repeatable build that tolerates the routing, vibration and repeated handling typical of production installations.
Frequently Asked Questions
Q: What connectors does it use? A: These jumpers typically use JIS F07/HPCF connectors (e.g. with Sumitomo CS-DL72 fiber); the exact interface is listed for the model.
